CDVI Centaur 2 Door Controller

The CTV900A is the core of the Centaur access control system and enables the management of up to  2,048 doors. The server, the readers, the expansion modules as well as all inputs and outputs are connected directly to the CTV900A . Systems with multiple controllers are connected by the RS485 communication bus. The integrated software architecture of the database allows any controller to make crucial decisions in a fraction of a second. Installer's choose the CTV900ATR for the quality, robustness and remarkably stable operation.

Technical Information

• Physical control of two doors (two input readers)

• Checking one physical door (input/output)

• Up to 6 additional doors can be added to the CTV900A with three additional CAA470A expansion modules

• Integrated database with a capacity of 10 920 chips: badges, digital fingerprints, codes

• 256 schedules

• 256 access levels

• Buffer memory for 2048 events

• 16 integrated inputs

• Two integrated outputs «locking» of 12 Vdc or 24 Vdc selectable with jumper

• 2 relay outputs (N / O - N / C)

• Fully integrated database architecture

• E-Bus technology

• Switching power supply of 2.5 A

• Supports communication formats Wiegand, ABA Track (magnetic stripe) and BCD (keypad)

• Easy maintenance and installation through removable terminals

• Battery integrated (2 x 12 V 7 AH)

• Protected by a lithium battery in case of complete interruption of the power supply

• Inputs for readers:2

• Inputs for keypads:2

• Multifunctional inputs:16

• 2 outputs for interlock (12Vdc and 24Vdc)

• Relay outputs: two C-shaped floating contact 5A / 30Vdc

• Outputs: N.C / N, O. 6 outputs 5V

• Dimensions (H x L x D): 39 cm x 33 cm x 10 cm

• Dimensions: 400 x 337 x 105mm

• Temperature: 5°C to 55°C

• Power Supply: 24Vac, 75VA, 50/60Hz

• Current: 2.5A maximum

• Batteries: 2 x 12Vdc, 7Ah

• RS485 communication with controllers

• E-Bus technology for the expansion modules

• Connecting distance of modules of 1220m to the CTV900A

• RS232 communication per serial port, modem link, or LAN / WAN
